Nec Cb751Q - 75" Collaboration Board/ 12/ 7 Usage/ 16:9/ 3840 X 2160/ 1 100:1/ Ips Panel/ Vga Hdmi Lan Usb/ 20 Point Touch/ Optional Ops Cb751Q
$4,726.00
| SKU: | 296336 |
|---|---|
| MPN: | CB751Q Link |
| Manufacturer: | https://www.necdisplay.com/ |
| Brand: | Nec |
| Warranty: | 1 Year Manufacturer's return to base |
| Availability: |
In stock |
| Fright Estimate |
Description
▼
Upgrade your lectures and meetings with NEC's all-in-one collaboration boards,
in three different sizes, featuring UHD resolution and up to 20 touch points.
Based on infrared touch technology the user experiences perfect usability with a
rapid touch response. Business and educational sessions start-up instantly with
built-in whiteboard and wireless screen sharing functionalities without any
hidden costs. The embedded annotation tool lets you annotate over any content
shown on the screen. For more demanding applications, the OPS slot provides the
opportunity to enhance the computing power. The NEC CB Series is the ideal
solution for your meeting room and class room.
- -Out-of-the-box collaboration - thanks to embedded computing with built-in annotation tools and wireless presentation capabilities.
- -Multi-Touch - true multi-touch support with up to 20 simultaneous touch points.
- -Protective Glass - premium toughened glass protects the security of the panel yet delivers a perfect touch experience with anti-glare coating to minimise reflections and fingerprints.
- -Simple operation - with easy front access to USB ports and controls for major functionalities
- -Ease of Use - enhance the display with an optional "Windows based" Slot-in-PC using the integrated Ultra High Resolution OPS option slot, thereby simplifying installations.
- -Cost Saving Device Management - save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
Specifications
▼
| Model | CB751Q |
|---|---|
| Platform | Touch Screen / Large Format Display |
| Classification | Business / Industry Specific |
| Screen Size (Inches) | 75.0 |
| Max Resolution (H x V Pixels) | 3840 x 2160 |
| Max Vertical Refresh Rate (Hz) | 26 / 135 |
| Aspect Ratio | 16:9 |
| Back Lighting | Direct LED Backlight |
| Panel Type | IPS |
| Brightness (cd/m2) | 350 |
| Contrast Ratio (Standard) | 1,100:1 |
| Viewing Angle (Horiz. Degrees) | 178 |
| Response Time | 8ms (G to G) |
| Bezel Width (mm) | 18 (left, right and top); 45 (bottom) |
| Height Adjust | No |
| Swivel | No |
| Pivot | No |
| Tilt Angle (Degree) | No |
| 3D Capable | No |
| TV Tuner | No |
| Touch Capable | Yes |
| Touch Technology | Multi Touch (20 point) IR |
| Touch Controller | USB |
| Speakers | 24.0W (12.0W + 12.0W) |
| HDMI Inputs | 3 |
| DVI-D Inputs | None |
| DP Inputs | None |
| VGA Inputs | 1 |
| Component (RGB) Inputs | None |
| AV Inputs | 1 |
| Serial Control | RS232 |
| Ethernet Control | RJ45 |
| Other Inputs | OPS Slot |
| Outputs | Audio Out, SPDIF Out, RJ45 Out |
| USB Function | 6 Port USB Hub |
| VESA Wall Mount (mm) | 800 x 400 |
| Software | NaviSet Admin 2, Mosaic Canvas |
| Unit Colour | Black |
| Power Supply | Mains Power Cable |
| Power Consumption (W) | 160.0W |
| Package Contents | 3 x Stylus; HDMI Cable; Power Cable; Remote Control; USB cable; User Manual; VGA cable; Wall Mount |
| Packaging | Retail |
| Unit Dimensions (W x H x D mm) | 1709.4 x 1020.0 x 86.8 |
| Weight (Kg) | 52.600 |
| Warranty | 3 Year |
Vendor Info
▼
Upgrade your lectures and meetings with NEC's all-in-one collaboration boards, in three different sizes, featuring UHD resolution and up to 20 touch points. Based on infrared touch technology the user experiences perfect usability with a rapid touch response. Business and educational sessions start-up instantly with built-in whiteboard and wireless screen sharing functionalities without any hidden costs. The embedded annotation tool lets you annotate over any content shown on the screen. For more demanding applications, the OPS slot provides the opportunity to enhance the computing power. The NEC CB Series is the ideal solution for your meeting room and class room.
⚫Out-of-the-box collaboration - thanks to embedded computing with built-in annotation tools and wireless presentation capabilities.
⚫Multi-Touch - true multi-touch support with up to 20 simultaneous touch points.
⚫Protective Glass - premium toughened glass protects the security of the panel yet delivers a perfect touch experience with anti-glare coating to minimise reflections and fingerprints.
⚫Simple operation - with easy front access to USB ports and controls for major functionalities
⚫Ease of Use - enhance the display with an optional "Windows based" Slot-in-PC using the integrated Ultra High Resolution OPS option slot, thereby simplifying installations.
⚫Cost Saving Device Management - save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
⚫Out-of-the-box collaboration - thanks to embedded computing with built-in annotation tools and wireless presentation capabilities.
⚫Multi-Touch - true multi-touch support with up to 20 simultaneous touch points.
⚫Protective Glass - premium toughened glass protects the security of the panel yet delivers a perfect touch experience with anti-glare coating to minimise reflections and fingerprints.
⚫Simple operation - with easy front access to USB ports and controls for major functionalities
⚫Ease of Use - enhance the display with an optional "Windows based" Slot-in-PC using the integrated Ultra High Resolution OPS option slot, thereby simplifying installations.
⚫Cost Saving Device Management - save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
