Tp-Link Archer Ax10 Next-Gen Wi-Fi Router Triple Core Cpu Ant(4) Lan (4) Archerax10

$187.00

SKU:	289536
MPN:	ARCHERAX10
Brand:	Tplink
Warranty:	1 Year Manufacturer's return to base
Availability:	Preorder 2-3 weeks
Fright Estimate

Description

▼

Specifications

▼

HARDWARE FEATURES
Processor	1.5 GHz Triple-Core CPU
Memory	256 MB RAM 16 MB Flash
Interface	1 × 1000/100/10 Mbps WAN Port 4 × 1000/100/10 Mbps LAN Ports
Button	WPS/Wi-Fi On/Off Button, Reset Button, Power On/Off Button
External Power Supply	12 V/5 A
Dimensions ( W x D x H )	10.2 × 5.3 ×1.5 in. (260.2 × 135.0 × 38.6 mm)
Antenna	4× Fixed Omni-Directional Antennas

WIRELESS FEATURES
Wireless Standards	IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz
Frequency	5 GHz and 2.4 GHz
Signal Rate	1201 Mbps (5 GHz, 11ax) 300 Mbps (2.4 GHz, 11n) Compatible with 802.11a/b/g/n/ac Wi-Fi standards
Reception Sensitivity	5 GHz: 11a 6Mbps:-97dBm, 11a 54Mbps:-79dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-63dBm 11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm 11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm 11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm 11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm 2.4 GHz: 11g 6Mbps:-91dBm, 11a 54Mbps:-74dBm 11n HT20_MCS0:-90dBm, 11n HT20_MCS7:-73dBm 11n HT40_MCS0:-88dBm, 11n HT40_MCS7:-70dBm
Transmit Power	CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz) FCC:<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz)
Wireless Functions	Enable/Disable Wireless Radio, Guest network, OFDMA
Wireless Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions

SOFTWARE FEATURES
WAN Type	Dynamic IP/Static IP/PPPoE
Management	Parental Control Guest Network
DHCP	Server, DHCP Client List, Address Reservation
Dynamic DNS	DynDns, NO-IP, TP-Link
Guest Network	2.4 GHz guest network × 1, 5 GHz guest network × 1
NAT	Port Forwarding, Port Triggering, UPnP, DMZ

OTHERS
Certification	FCC, CE, RoHS
Package Contents	Wireless Router Archer AX10 Power Adapter RJ45 Ethernet Cable Quick Installation Guide
System Requirements	Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem Subscription with an internet service provider (for internet access)
