With configurable per-port power distribution, our Gigabit 12-port switch is the ideal solution for variable power deployments, such as point/tilt/zoom cameras, lighting controllers, and point-of-sale kiosks.

Winner of Network Computing’s
2017 New Hardware Product of the Year

The IE300-12GP is a Power over Ethernet Power Sourcing Device (PoE PSD), which is compliant with IEEE802.3af and IEEE802.3at standards.

Each port supplies either 15.40W PoE with 12.95W available to the powered device, or 30.00W PoE+ with 25.50W available to the powered device.

Four ports are configurable for Hi-PoE (also known as Ultra PoE, High PoE, PoE++, and others because there is no current standard), which uses all four pairs in the cable to provide up to 60W—double the capacity of PoE+.

You can configure the overall power budget and the power feeding limit on a per-port basis, to establish a close relationship between the power sourcing feature with the real capabilities of the external Power Supply Unit (PSU).

Enabling the unique High Availability Network Power (HANP) feature, the switch retains PoE sourcing during restart events, such as those due to operator command, software exception, watchdog timeout or diagnostic failures. The restart event is not propagated to the end devices, and camera operation is not affected.

The enhanced Thermal Shutdown feature acts when the switch exceeds the safe operating temperature; different stages allow to preserve services and prevent damage.
When the operating temp reaches critical levels, the system cuts the PoE sourcing to non-critical interfaces first, then to critical interfaces; if the temp still increases, then all services will be disabled and the system will enter the standby mode.
The system restores operation when the temperature returns at acceptable levels.

Product configuration:

• 4-port, 100/1000X SFP
• 8-port, 10/100/1000T
• 24Gbps switch fabric and 17.8Mpps forwarding packet rate (64-byte size)
• 16K MAC addresses
• 4K simultaneous VLANs
• 9KB jumbo frame size
• 8 QoS priority queues
• 1K (Layer 2), 256 (Layer 3) Multicast groups
• 8-port, IEEE802.3af and IEEE802.3at power sourcing
• 4-port, Hi-PoE power sourcing (60W)
• PoE power budget up to 240W
• Configurable PoE power budget and power feeding limit on a per-port basis
• HANP to retain PoE sourcing over restart
• Enhanced Thermal Shutdown
