Hardware Specifications
CPU
CPU Model Intel Atom C2538
CPU Architecture 64-bit
CPU Frequency Quad Core 2.4 GHz
Hardware Encryption Engine (AES-NI)
Memory
System Memory 2 GB DDR3
Memory Module Pre-installed 2 GB (2 GB x 1)
Total Memory Slots 2
Memory Expandable up to 16 GB (8 GB x 2)
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 8
Maximum Drive Bays with Expansion Unit 12
Compatible Drive Type* (See all supported drives)
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity 112 TB (14 TB drive x 8) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 168 TB (112 TB + 14 TB drive x 4) (Capacity may vary by RAID types)
Maximum Single Volume Size 108 TB
Hot Swappable Drive
Notes
"Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
Expansion of the internal volume is only supported if the combined single volume size does not exceed the maximum limit of 108TB.
