Essentials

Board Number

NUC10i5FNB

Board form factor

UCFF (4" x 4")

Socket

Soldered-down BGA

Internal drives supported

1

Internal Drive Form Factor

M.2 SSD

TDP

25W

DC Input Voltage

19V DC

Processor included

Intel Core i5-10210U Processor

Lithography

14nm

Supported OS

Windows 10 (64-bit)

Warranty

3 Years

Memory & Storage

Max Memory Size

64 GB

Memory Types

DDR4-2666   1.2V   SO-DIMM

Max# Memory Channels

2

Max Memory Bandwidth

42.6 GB/s

Max# of DIMMs

2

ECC Support

No

Graphics

Processor Graphics

Intel UHD Graphics

Integrated Graphics

Yes

Graphics Output

HDMI 2.0a; USB-C (DP 1.2)

#of Displays Supported

3

Expansion Options

PCI Express revision

Gen3

PCIE Express Configuration

M.2 slot with PCIe X4 lanes

Memory Card slot

SDXC with UHS-II support

M.2 Card slot (storage)

22x42/80

IO Specifications

# of USB Ports

7

USB Configuration

2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers

USB Revision

2.0, 3.1 Gen2

USB 2.0 Configuration (External + Internal)

0 + 2

USB 3.0 Configuration (External + Internal)

2B 2F + 0

Total # of SATA Ports

2

Max # of SATA 6.0 Gb/s Ports

2

Audio (back channel + front channel)

7.1 digital (HDMI mDP); L+R mic (F)

Integrated LAN

Intel Ethernet Connection I219-V

Integrated Wireless

Intel Wi-Fi 6 AX201

Integrated Bluetooth

Yes

Consumer Infrared Rx Sensor

Yes

Additional Headers

CEC, 2x USB2.0, FRONT_PANE

# of Thunderbolt 3 Ports

1

Package Specifications

Chassis Dimensions

117 x 112 x 38mm

Advanced Technologies

Intel Optane Memory Supported

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel vPro Platform Eligibility

No

TPM

No

Intel HD Audio Technology

Yes

Intel Rapid Storage Technology

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel Platform Trust Technology (Intel PTT)

Yes

Security & Reliability

Intel AES New Instructions

Yes
