Dell C5517h 55in Led Fhd 1920x1080 3000:1 5ms Hdmi C5517h
| SKU: | 247225 |
|---|---|
| MPN: | C5517H Link |
| Manufacturer: | http://www.dell.com/ |
| Brand: | Dell |
| Warranty: | 1 Year Manufacturer's return to base |
| Availability: |
Preorder 2-3 weeks |
| Fright Estimate |
Description
A display as bright as your ideas
See your work in a whole new light with incredible on-screen clarity and bright imagery, even in fully lit meeting rooms.
- Exceptional clarity: Microsoft Office applications like Excel and PowerPoint display beautifully on this 55-inch anti-glare screen with Full HD 1920 x 1080 resolution.
- Outstanding view: count on a display that’s optimised for fonts and keeps text sharp and clear. Plus, Dell Display Manager software enables customised screen layouts.
- Great view from any angle: colours remain consistent across a wide 178°/178° viewing angle so everyone in the room gets the same great view.
- Bold colours: Deep, rich hues command your audience's attention.
Specifications
isplay
- Diagonal VIS (Viewable Image Size)
1386.8 mm (54.6 inch)
Preset Display Area(H X V)
1209.6 mm (47.6 inch)
680.4 mm (26.8 inch)
823011.8 mm² (1275.7 inch²)
Typical Response Time
8ms Typical (G to G)
Aspect Ratio
16:9
Panel Technology, Surface
Vertical Alignment
Backlights
LED light bar system
Luminance (Brightness)
350 cd/m² (typical)
Viewing Angle (Vertical/Horizontal)
178°/178°
Color Support
Color Gamut: CIE1976 (85 %) / CIE1931 (72 %)
Number of Colors
16.7 Million
Bezel Color
Black
Pixel Pitch
0.21 mm (W) 0.63 mm (H)
Contrast Ratio (Typical)
Dynamic Contrast Ratio (DCR)
3000 to 1 (typical)
Resolution
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
56 Hz to 76 Hz (automatic)
Maximum resolution
1920 x 1080 at 60 Hz
Remote Asset Management
RS232 input (D-Sub 9pins)
Speakers
Integrated speakers (10W x 2)
Panel - bits
6 bits + FRC panel
Duty cycle
12/7
Connectivity
- HDMI x 2
DP
VGA
USB 2.0 Ports
USB 3.0 x 3 including charging
RS232 port
Audio Line in port
Audio Line out port
Dimensions
- Viewable Image Dimension
Height: 786.0 mm (30.9 inches)
Width: 1241.0 mm (48.9 inches)
Depth: 245.0 mm (9.4 inches)
Mount Interface
VESA 400 x 400
Monitor Head (No Stand)
Height: 721.5 mm (28.4 inches)
Width: 1241.0 mm (48.9 inches)
Depth: 64.8 mm (2.6 inches)
Weight (panel only) for VESA mount - no cables)
20.4 kg (44.7 lb)
Weight (monitor + cables)
24.6 kg (53.7 lb)
Weight (with packaging)
32.2 kg (70.8 lb)
Horizontal
1209.6 mm (47.6 inch)
Viewable Screen Area (Horizontal x Vertical)
823011.8 mm² (1275.7 inch²)
Power
- Power Usage
AC input voltage
100 VAC to 240 VAC / 50 Hz or 60 Hz +/- 3 Hz / 2.5 A(Max)
Operating (Typical - Maximum)
70W - 170W
Active Off
Less than 0.3W
Switched Off
Less than 0.3W
Environmental
-
Temperature
Operating: 0°C to 40 °C (32 °F to 104 °F)
Nonoperating: (Shipping Conditions)
Storage: -20 °C to 60 °C (-4 °F to 140 °F)
Shipping: -20 °C to 60 °C (-4 °F to 140 °F)Humidity
Operating: 20 to 80 % (non-condensing)
Nonoperating: (Shipping Conditions)
Storage: 10 % to 90 % (non-condensing)
Shipping: 10 % to 90 % (non-condensing)Altitude
Operating: 5,000 m (16,387 ft) max
Nonoperating: (Shipping Conditions)
12,191 m (40,000 ft) max
Thermal dissipation
410 BTU / hour (maximum)
256 BTU / hour (typical)
Regulatory
- Product Safety, EMC and Environmental Datasheets
Dell Regulatory Compliance Home Page
Dell and the Environment
What's in the Box
Beside Monitor
Stand
Drivers
Documentation media
Quick Set Up Guide and Safety Information
Cable(s) Provided (m)Power cables for
Power cable (varies by countries)
VGA Cable
HDMI Cable
DP to DP Cable
USB Upstream Cable
Others
Remote Control
Table stand
Vendor Info
| Marketing Text | 55-inch conference room monitor ideal for small meetings. Featuring incredible viewing that's perfect for an audience of 4-8 people.See your work in a whole new light with incredible on-screen clarity and bright imagery, even in fully lit meeting rooms. |
| PI Date | Mar 2017 |
| Brand Name | Dell |
| Manufacturer Web Site | http://www.dell.com |
| Product Model | C5517H |
| Product Type | LED Display |
| Aspect Ratio | 16:9 |
| Brightness | 350NIT |
| Color | Black |
| Contrast Ratio | 3000:1 |
| Dot Pitch | 0.21 x 0.63mm |
| High Definition Compatibility | FullHD |
| LCD Backlight Technology | LED |
| Resolution | 1920 x 1080 |
| Response Time | 8ms |
| Screen Size | 54.6inch |
| Depth (mm) | 64.8 |
| Height (mm) | 721.5 |
| Width (mm) | 1241.0 |
| Weight (Kg) | 20.4 |
| Power Wattage | 70Watt |
| Color Supported | 16.7million |
| Scanning Frequency (Horizontal) | 30 - 83KHz |
| Scanning Frequency (Vertical) | 56-76Hz |
| Viewing Angle (Horizontal) | 178degree |
| Viewing Angle (Vertical) | 178degree |
| Other Features | * Exceptional clarity * Speakers: Integrated speakers |
