HIGHLIGHTS

Technical Specifications

Camera

Camera Hardware Profile

• 1/2.7” Progressive CMOS sensor
• Minimum illumination:
  • B/W mode (IR LEDs on): 0 lux
• Lens focal length: 3.3 mm
• Aperture: F2.4
• 7 metre IR illumination distance
• Angle of view:
  • Horizontal: 117°
  • Vertical: 59°
  • Diagonal: 135°
• Built-in Infrared-Cut Removable (ICR) Filter
• Built-in microphone and speaker

Image Features

• Pinch to Zoom Digital zoom
• Configurable sound detection level
• Time stamp and text overlay
• Configurable resolution
• Configurable motion detection windows

Video Compression

• H.264 streaming
• MJPEG for still images

Video Resolution

• Main Profile: 1080p (1920 x 1080) at up to 30 fps
• Second Profile: 720p (1280 x 720) at up to 15 fps

Audio Support

• MPEG-2 AAC LC

Connectivity

• 802.11n/g/b wireless with WPA/WPA2 encryption
• microSD card slot
• Bluetooth 4.0

Network Protocols

• IPv4, IPv6, ARP, TCP, UDP, ICMP
• DHCP client
• Bonjour
• HTTPS

Features

Event Management

• Motion detection
• Sound level detection
• Event recording to an SD card²
• Event notification and snapshot/video clip download to mobile device
• mydlink Cloud Recording²

Mobile Support

• mydlink app for iOS and Android devices¹,³

Physical

Weight

• Camera: 290 grams ± 5%
• Wall mount: 32 grams ± 5%

Power Adapter

• Input: 100 to 240 V AC, 50/60 Hz
• Output: 5 V DC 2 A (Micro-USB)
• Cable length: 7m (Camera:3m, Power Adapter: 4m)

Power Consumption

• Maximum:  6 watts ± 5%

Temperature

• Operating: -25 to 45 °C
• Storage: -25 to 70 °C

Humidity

• Operating: 20% to 80% non-condensing

Certifications

• CE
• CE LVD
• FCC
• ICES
• RCM

<sup>1. Smartphone or tablet must have access to the Internet via Wi-Fi or mobile Internet.
2. Use of audio or video equipment for recording the image or audio of a person without their knowledge and consent is prohibited in certain countries or jurisdictions. The end-user assumes all liability for compliance with applicable local laws.
3. Please refer to the mobile app’s store page to check whether your device is compatible.</sup>

Maximum Video Resolution :	1920 x 1080 @30fps
Sound Detection :	Yes
Built-in Microphone :	Yes
Dimensions (Size) :	88 x 88 x 6906 mm
Wireless Connectivity :	802.11n
Indoor / Outdoor :	Outdoor
Video Compression :	MJPEG|H.264
Warranty :	1-Year Limited Warranty
Night Vision :	Yes
Motorised Pan / Tilt :	No
ePTZ :	No
MicroSD Card Slot :	Yes
Digital Zoom :	Pinch to Zoom
Two-way Audio :	Yes
Email Notification :	No
Ethernet Port :	No
Wireless Range Extender Built In :	No
Built-in Speaker :	Yes
Motion Detection :	Yes
Camera Type :	Outdoor
HomeKit (Apple) Enabled :	No

The DCS-8600LH Full HD Outdoor Wi-Fi Camera boasts a wide-angle lens that easily captures your entireroom, wall-to-wall, in high-quality 1080p. You will know what is happening day or night with built innight vision, motion and sound detection sending notifications to the mydlink™ app. The rotatable headmakes discrete installations easy even on ceilings. It has an IP65 rating, which means it can withstandoutdoor weather environments such as rain or shine, and on cold and hot days it still can be outdoors.Features? High quality Full HD sensor providesdetailed snapshots and crisp video? Weatherproof housing? Built-in IR LEDs to capture videoin low-light environments or evencomplete darkness up to 7 m (23 ft)? Motion and sound level detection? Push notification for events and savevideo clips to microSD card or sendto cloud storage? Uses Wireless N so you can install thecamera anywhere with ease? Uses 2T/2R high efficiency WiFi module to improve wirelessperformance? Backwards compatible with802.11g/b? View and manage your camera usingthe mydlink™ app? Two-way audio? 135-degree viewing angle? AES128-encrypted video and audiostreaming
