The NETGEAR ProSAFE® Easy-Mount Switch Family Overview
The NETGEAR ProSAFE® Easy-Mount Switch allows you to put more PoE/PoE+ ports Virtually Anywhere™ with its unique mounting system.
The Easy-Mount Switch family comes with a full set of software features such as traffic prioritization, VLANs, QoS and PoE power allocation.
Moreover the Easy-Mount switches comes with Energy Efficient Ethernet for maximum power savings.
Easy-Mount and Low Noise Operation
Deploy your PoE/PoE+ switch closest to your PoE/PoE+ devices and put your PoE/PoE+ ports exactly where you need them.
Install your ports up in the ceiling, strapped to a pole, mounted under a desk or tabletop. If you wish you also can rack mount the GS408EPP switch on a 19-inch standard rack. You can even rack mount 2 GS408EPP switches back to back in a single 1U.
Thanks to the active fans the GS408EPP is a silent switch, well below offices ambient background noise.


PoE/PoE+ Support
Power-Over-Ethernet (PoE) option available for powering IP Security Cameras, VOIP phones, wireless access points, and other PD-powered devices.
With eight (8) PoE/PoE+ Gigabit Ethernet ports (802.3af, 802.3at) providing up to 30W per port, and a power budget of 124W, provide power and connectivity across one wire to power-hungry PoE devices like 802.11ac Wave 2 Access Points, Pan/Tilt/Zoom/HD Security Cameras, security door locks, and other IoT devices.
Easy-Mount "Virtually Anywhere" Mounting System
The innovative mounting system gives you the flexibility to place the Easy-Mount Switch in locations where other switches will not go. Whether it's directly on a wall, strapped to a pole, under the meeting table in a conference room or in a server closet, vertical or horizontal, flat or perpendicular, the unique mounting system allow you to control exactly how and where your ports and cables are deployed.

Networking Management Features
The Easy-Mount Switches can go beyond plug-and-play connectivity with additional ProSAFE Switch networking features, allowing businesses to segment the network with VLANs or prioritize voice and video traffic with QoS. IGMP Snooping allows for optimized multimedia delivery and port trunking adds redundancy to uplinks and servers. Setup and configuration is simple using the web browser-based configuration GUI.

View Larger

NETGEAR Warranty
Easy-Mount switches are backed by a NETGEAR ProSAFE® Limited Lifetime Hardware Warranty.
Lifetime Next Business Day Hardware Replacement.
ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days.
ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat

Hardware
8-port Gigabit Ethernet Ports
8 PoE/PoE+ ports (802.3af, 802.3at) with 124W PoE/PoE+ Budget
Virtually AnywhereTM Easy-Mount system allows for:
1. On a Wall.
2. Under a Tabletop/Desktop.
3. On a rectangular or round pole.
4. Up in the ceiling.
5. In a standard 19-inch rack
Multi-directional power cable can be routed outwards or downwards
Internal power supply (simple power cord from switch to outlet)
LED lights can be turned off for non-distracting placement next to a TV
Performance
192KB packet buffer memory (dynamically shared across only used ports)
16 Gbps non-blocking fabric (bandwidth)
4 Priority queues
Weighted Round Robin (WRR) priority queuing
4K Media Access Control (MAC) addresses with 48-bit MAC address
128 Multicast groups
64 VLANs
Jumbo frames up to 9K packet size supported
VLANs
IEEE 802.1Q VLAN tagging
Port-based VLANs (physical)
Multicast
IGMP snooping, v1, v2 and v3
Blocking of unknown multicast traffic
Link Aggregation
IEEE 802.3ad - Static LAGs
2 LAGs with max 4 members in each LAG
Quality of Service (QoS)
Port-based rate limiting (ingress and egress)
Port-based QoS
IEEE 802.1p COS
IPv4 DSCP
IPv4 ToS
Weighted Round Robin (WRR)
Network Security
Broadcast, multicast, unknown unicast storm control
DoS attacks prevention
Reliability, Performance and Troubleshooting
Port mirroring both on ingress and egress traffic
Jumbo frame support
Broadcast storm control
Cable diagnostics
Loop detection
Energy Efficient Ethernet (IEEE 802.3az) compliant
Broadcast, multicast, unknown unicast storm control
Management
Password management
Web browser-based graphical user interface (GUI) for advanced configuration and management
ProSAFE Plus Configuration Utility (PCU) for multi-switch management (requires Windows PC)
Firmware upgrade via HTTP (Web GUI) or TFTP (Plus Utility)
Config file transfers (backup, restore) using web browser-based management GUI or Plus Utility
Port mirroring; many-to-one port mirroring
Energy Efficient Ethernet (EEE) IEEE 802.3az (deactivated by default)
Short cable power reduction
Auto power-down
Broadcast, multicast, unknown unicast storm control
DHCP client
NETGEAR Warranty
This product is backed by a NETGEAR ProSAFE® Limited Lifetime Hardware Warranty.
Lifetime Next Business Day Hardware Replacement. Click here for coverage, availability and terms and conditions.
ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.
ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat. (Remote diagnostics performed by our technical experts for prompt resolution of technical issues).

PoE/PoE+ Gigabit Ethernet Ports
With eight (8) PoE/PoE+ Gigabit Ethernet ports (802.3at) providing up to 30W per port, and a power budget of 124W, provide power and connectivity across one wire to power-hungry PoE devices like 802.11ac Wave 2 Access Points, Pan/Tilt/Zoom/HD Security Cameras, security door locks, and other IoT devices.

Easy-Mount "Virtually Anywhere" Mounting System
The industry-first Easy-Mount mounting system allows you to put your PoE+ ports exactly where you want them: on a wall, under a tabletop/desktop, on a pole, or even up in the ceiling on the ventilation ducts, horizontal or vertical.

Two-in-one 1U Rackmount Capable
Because all connections are on the front (both power and ethernet connections), and because of it's small size, you can mount two GS408EPP Easy-Mount switches within a single 1U slot by mounting one facing out the front, and the other facing out the back of your rack.
SOFTWARE FEATURES
Comprehensive QoS Features
Advanced controls for optimized network performance and better delivery of mission-critical traffic such as voice and video. Ingress and egress rate limiting allows for bandwidth shaping for mitigating network resources constraints or for optimizing guest access bandwidth on the network.
Port-based or 802.1p-based prioritization
Layer 3-based (DSCP) prioritization
Port-based ingress and egress rate limiting

IGMP Snooping
For improved network efficiency on delivering multicast traffic. Save cost and improve network efficiency by ensuring multicast traffic only reaches designated receivers without the need of an extra multicast router.
Loop Detection / Auto DoS Prevention
Detect accidental network loops and protect against DoS (Denial of Service) attacks.

Port-based & 802.1Q-based VLANs
Segment network into smaller groups for more secure and efficient use of network resources.
PoE Per Port Controls
Advanced per port PoE controls for remote power management of PoE connected devices (eg. Wireless AP, IP security cameras, LED lighting, door locks, IoT devices…) including:
Enable/disable PoE power per port
PoE prioritization
PoE power class configuration (802.3af, 802.3at)
User-defined PoE power limit per port (override detected Class)
Power cycle PoE per port

Port Trunking / Link Aggregation (LAG)
Build up bigger bandwidth to support aggregated uplink/downlink traffic.
Energy Efficient Ethernet (IEEE 802.3az)
For maximum power savings and reduced energy costs.

Port Mirroring
For better and quicker network diagnostics and troubleshooting.
Cable Test
Easily identify bad Ethernet cables.
