Unique Feature

ASRock Super Alloy

-       Premium 50A Power Choke

-       Sapphire Black PCB

-       High Density Glass Fabric PCB

ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)

ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

ASRock Live Update & APP Shop

CPU

-       Supports 10th Gen Intel Core Processors (Socket 1200)

-       Digi Power design

-       7 Power Phase design

-       Supports Intel Turbo Boost Max 3.0 Technology

Chipset

-       Intel H410

Memory

-       Dual Channel DDR4 Memory Technology

-       2 x DDR4 DIMM Slots

-       Supports DDR4 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory

-       Supports ECC UDIMM memory modules (operate in non-ECC mode)

-       Max. capacity of system memory: 64GB

-       Supports Intel Extreme Memory Profile (XMP) 2.0

-       15 micron Gold Contact in DIMM Slots15 micron Gold Contact in DIMM Slots

BIOS

-       128Mb AMI UEFI Legal BIOS with multilingual GUI support

-       ACPI 6.0 Compliant wake up events

-       SMBIOS 2.7 Support

-       CPU Core/Cache, GT, DRAM, VPPM, PCH 1.05V, VCCST, VCCSA Voltage Multi-adjustment

Graphics

-       Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz

-       Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz

-       Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

-       Supports HDCP 2.3 with DVI-D and HDMI 1.4 Ports

-       Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port

Audio

-       7.1 CH HD Audio (Realtek ALC887 Audio Codec)

-       Supports Surge Protection

LAN

-       Gigabit LAN 10/100/1000 Mb/s

-       Giga PHY Intel I219V

-       Supports Wake-On-LAN

-       Supports Lightning/ESD Protection

-       Supports Energy Efficient Ethernet 802.3az

-       Supports PXE

Slots

-       1 x PCI Express 3.0 x16 Slot

-       1 x PCI Express 3.0 x1 Slot

-       1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

Storage

-       4 x SATA3 6.0 Gb/s Connectors

-       1 x Ultra M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module

Connector

-       1 x Print Port Header

-       1 x COM Port Header

-       1 x SPI TPM Header

-       1 x Chassis Intrusion and Speaker Header

-       1 x CPU Fan Connector (4-pin)*

-       1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**

-       2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***

-       1 x 24 pin ATX Power Connector

-       1 x 8 pin 12V Power Connector

-       1 x Front Panel Audio Connector

-       2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)

-       1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)

Rear Panel I/O

-       1 x Antenna Bracket

-       1 x PS/2 Mouse/Keyboard Port

-       1 x D-Sub Port

-       1 x DVI-D Port

-       1 x HDMI Port

-       4 x USB 2.0 Ports (Supports ESD Protection)

-       2 x USB 3.2 Gen1 Ports (Supports ESD Protection)

-       1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

-       HD Audio Jacks: Line in / Front Speaker / Microphone

Accessories

-       Quick Installation Guide, Support CD, I/O Shield

-       2 x SATA Data Cables

-       2 x Screws for M.2 Sockets

Form Factor

-       Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm

Certifications

-       FCC, CE

-       ErP/EuP ready (ErP/EuP ready power supply is required)
