| Basic |
| Brand Name: | Cisco |
| Ethernet Technology: | Fast Ethernet |
| | Gigabit Ethernet |
| Form Factor: | Desktop |
| | Rail-mountable |
| Layer Supported: | 2 |
| Manageable: | Yes |
| Media Type Supported: | Twisted Pair |
| Network Technology: | 10/100/1000Base-T |
| | 10/100Base-TX |
| PoE (RJ-45) Port: | No |
| Power Source: | Power Supply |
| Product Family: | IE-2000 |
| Product Type: | Ethernet Switch |
| Redundant Power Supply Supported: | Yes |
| Stack Port: | No |
| Total Number of Network Ports: | 6 |
| Battery Information |
| Power Source: | Power Supply |
| Display & Graphics |
| Maximum Memory: | 1 GB |
| General Information |
| Brand Name: | Cisco |
| Manufacturer Part Number: | IE-2000-4T-G-B |
| Manufacturer Website Address: | http://www.cisco.com |
| Manufacturer: | Cisco Systems, Inc |
| Product Model: | IE-2000-4T-G-B |
| Product Name: | IE-2000-4T-G-B Ethernet Switch |
| Product Series: | IE-2000 |
| Product Type: | Ethernet Switch |
| Interfaces/Ports |
| Bypass: | No |
| Ethernet Technology: | Fast Ethernet |
| LRE Port: | No |
| Management Port: | Yes |
| Modular: | No |
| Number of Network (RJ-45) Ports: | 6 |
| PoE (RJ-45) Port: | No |
| Stack Port: | No |
| Token Ring Port: | No |
| Total Number of Network Ports: | 6 |
| USB: | Yes |
| Uplink Port: | Yes |
| Management & Protocols |
| Manageable: | Yes |
| Management: | - Telnet
- HTTPS
- SNMPv3
- CNA
- VLAN
- QoS
- DHCP
- SSH
- CiscoWorks LAN Management Solution (LMS)
- Web Base Management
|
| Management |
| Management: | - Telnet
- HTTPS
- SNMPv3
- CNA
- VLAN
- QoS
- DHCP
- SSH
- CiscoWorks LAN Management Solution (LMS)
- Web Base Management
|
| Media & Performance |
| Ethernet Technology: | Fast Ethernet |
| Media Type Supported: | Twisted Pair |
| Network Technology: | 10/100/1000Base-T |
| | 10/100Base-TX |
| Twisted Pair Cable Standard: | Category 5 |
Memory
Flash Memory: 64 MB
Maximum Memory: 1 GB
Memory Card Supported: SD
Memory Technology: DRAM
Standard Memory: 256 MB
Miscellaneous
Form Factor: Desktop
Network & Communication
Ethernet Technology: Gigabit Ethernet
Layer Supported: 2
Network Technology: 10/100/1000Base-T
10/100Base-TX
Network
Network Technology: 10/100/1000Base-T
10/100Base-TX
Physical Characteristics
Depth: 114.6 mm
Form Factor: Desktop
Rail-mountable
Height: 129.5 mm
Weight (Approximate): 1.11 kg
Width: 74.9 mm
Power Description
PoE (RJ-45) Port: No
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Product Information
Form Factor: Desktop
Rail-mountable
Power Source: Power Supply
Width: 74.9 mm
Reliability
MTBF: 374052 Hour
Storage
Flash Memory: 64 MB
Memory Card Supported: SD
Technical Information
Ethernet Technology: Gigabit Ethernet
Management:
Telnet
HTTPS
SNMPv3
CNA
VLAN
QoS
DHCP
SSH
CiscoWorks LAN Management Solution (LMS)
Web Base Management
Media Type Supported: Twisted Pair
Memory Card Supported: SD
Memory Technology: DRAM
Modular: No
Number of Network (RJ-45) Ports: 6
Power Source: Power Supply
USB: Yes
