Supports 10th Gen Intel® Core™ Series Processors
Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
Intel® Optane™ Memory Ready
14 Phase Digital VRM Solution with 90A Smart Power Stage and Tantalum Polymer Capacitors Array
Shielded Memory Routing for Better Memory Overclocking
Newly Invented Thermal Design with Fins-Array II Heatsink and Direct Touch Heatpipe II
Onboard Intel® WiFi 6 802.11ax 2T2R & BT5 with AORUS Antenna
125dB SNR AMP-UP Audio with High-End ESS SABRE 9118 DAC, ALC1220 and WIMA Audio Capacitors
Blazing Fast Intel® 2.5GbE LAN with cFosSpeed
USB TurboCharger for Mobile Device Fast Charge Support
Triple Ultra-Fast NVMe PCIe 3.0 x4 M.2 with Thermal Guards II
RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP and Noise Detection
Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card

CPU
1. Support for 10th Generation Intel® Core™
Chipset
1. Intel® Z490 Express Chipset

Memory

1. Intel® Core™ i9/i7 processors:
3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Onboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support:
1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
Maximum shared memory of 512 MB
Storage Interface

1 x M.2 connector
6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
Form Factor

1. ATX Form Factor; 30.5cm x 24.4cm
