Supports 10th Gen Intel® Core™ Series Processors
Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
Intel® Optane™ Memory Ready
Direct 11+1 Phases Digital VRM Solution with DrMOS
Enlarged VRM Heatsink with 5W/mK Thermal Conductive Pad
Intel® GbE LAN with cFosSpeed Internet Accelerator Software
Multi-Way Graphics Support with Dual Armor and Ultra Durable™ Design
ALC1200 Multi-Channel Audio with High Quality Audio Capacitors and Audio Noise Guard
Dual Ultra-Fast M.2 with PCIe Gen3 X4 (1 with Thermal Guard) & SATA Interface
Intel® Native USB 3.2 Gen2 Type-A with Speed Up To 10Gbps
RGB FUSION 2.0 Support Addressable LED & RGB LED Strips
Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
Q-Flash Plus Updates BIOS without Installing the CPU, Memory and Graphics Card
CEC 2019 Ready, Save the Power as Easy as One Click
Lightning-Fast Intel® Thunderbolt™ 3 AIC Support

CPU
1. Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7
Chipset
1. Intel® Z490 Express Chipset
Memory
Support for DDR4 2666/2400/2133 MHz memory modules
3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
LAN
1. Intel® GbE LAN chip (1000 Mbit/100 Mbit)
Expansion Slots
1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
2. 1 x PCI Express x16 slot, running at x4
3. 3 x PCI Express x1 slots
Storage Interface
Form Factor
1. ATX Form Factor; 30.5cm x 23.0cm
