Socket AM4
CPU (Max Support) RYZEN 9
Chipset AMD® B450 Chipset
DDR4 Memory 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
For AMD Ryzen Gen3 (R5/R7/R9)
2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE)
For AMD Other CPU
2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE)
Memory Channel Dual
DIMM Slots 4
Max Memory (GB) 64
PCI-E x16 2
PCI-E Gen Gen3(PCI_E1), Gen2(PCI_E4)
PCI-E x1 4
SATAIII 6
M.2 Slot 1
RAID 0/1/10
TPM (header) 1
LAN 1x Realtek® 8111H
USB 3.2 ports (Front) 2(Gen1, Type A)
USB 3.2 ports (Rear) 2(Gen2, Type A), 2(Gen1, Type A)
USB 2.0 ports (Front) 4
USB 2.0 ports (Rear) 2
Serial ports(Front) 1
Audio ports (Rear) Realtek® ALC892 Codec
DVI-D 1
VGA 1
HDMI 1
DirectX 12
Form Factor ATX
CrossFire Y
