FAN Specification

Size 120x120x25 mm

Mounting hole spacing 105x105 mm

Connector & pin-configuration 4-pin PWM

Cable length 40cm

Bearing SSO2

Blade geometry Heptaperf™

Frame technology FocusedFlow™

Material Fibre-glass reinforced polyamide

Ingress protection IP67

Motor type Three-phase

Rotational speed (+/- 10%) 3000 RPM

Min. rotational speed (PWM, +/-20%) 750 RPM

Rotational speed @ 12V (+/- 10%) 1600 RPM

Airflow 186,7 m³/h

Acoustical noise 43,5 dB(A)

Static pressure 7,63 mm H₂O

Max. input power 4,32 W

Max. input current 0,18 A

Operating voltage 24 V

Voltage PWM signal 5 V

MTTF > 150.000 h

Scope of delivery Fan 4 Fan Screws

Warranty 6 years

Manufacturer: Noctua. Conceived for industrial heavy-duty applications that require enhanced cooling performance and advanced ingress protection, the NF-F12 industrialPPC (Protected Performance Cooling) is a ruggedised high-speed version of the award-winning retail model. The 24V Q100 variant uses Noctuas AEC-Q100 qualified wide input range NE-FD4 motor driver IC in order to support 24V-based industrial and automotive applications. Its sophisticated inrush current suppression and extreme electrical robustness with extended burst and surge immunity allow it to operate safely in sensitive or hostile electronic environments. Thanks to the outstanding aerodynamic efficiency of the NF-F12 design and the use of a novel three-phase motor, the industrialPPC version provides superior airflow and pressure capacity while keeping noise and power consumption at a moderate level as against comparable high-speed fans. While its fibre-glass reinforced polyamide construction and certified water and dust protection make the NF-F12 industrialPPC suitable for operation in challenging surroundings, the renowned SSO2 bearing technology guarantees an MTBF of over 150,000hrs. Topped off with Noctuas trusted reliability and 6-year manufacturers warranty, the NF-F12 industrialPPC is an ideal choice for highly demanding applications that require superior flow rates and ultimate dependability.
