Intel Raid Module, 1gb 3108, 8x Sas/ Sata 12g, Raid 0/ 1/ 10/ 5/ 50/ 6/ 60 Rms3cc080
$811.00
| SKU: | 220675 |
|---|---|
| MPN: | RMS3CC080 Link |
| Manufacturer: | http://www.intel.com.au/content/www/au/en/homepage.html |
| Brand: | Intel |
| Warranty: | 1 Year Manufacturer's return to base |
| Availability: |
In stock |
| Fright Estimate |
Description
▼
Specifications
| - Essentials | ||
| Status | Launched | |
| Launch Date | Q3'14 | |
| Expected Discontinuance | 2H'20 | |
| Description | 12Gb/s (SAS 3.0) 8 internal port SAS/SATA mezzanine card built with PCIe 3.0 dual core RAID-On-Chip (ROC), RAID levels 0/1/10/5/50/6/60, and support for optional Maintenance Free Backup Unit and Premium Feature upgrade keys. | |
| Target Market | Mainstream | |
| Board Form Factor | Storage Connector Module | |
| Data Transfer Rate | 12 Gb/s | |
| Supported Devices | SAS/SATA | |
| Supported Operating Systems | Windows, Linux, Solaris, VMware | |
| Compatible Cache Backup Options | AXXRMFBU5 | |
| RAID Level Supported | 0, 1, 10, 5, 50, 6, 60 | |
| JBOD Mode | No | |
| # of Ports Internal | 8 | |
| # of Devices Supported | 128 | |
| Embedded Memory | 1GB | |
| PCIe Host Interface | PCIe x8 Gen3 | |
| IO Processor Model | LSI3108 | |
| Keying | SIOM Connector | |
| Connector Orientation | Side | |
| Extended Warranty Available for Purchase (Select Countries) | Yes | |
| Additional Features | Support for optional Maintenance Free Backup Unit and Premium Feature upgrade keys. | |
| Included Items | (1) Intel® Integrated RAID Module RMS3CC080, (4) standoffs, and (4) standoff locking pins | |
| Datasheet | Link | |
| Recommended Customer Price | N/A | |
