Startech 2-port Vga Auto Switch Box With Priority Switching And Edidcopy - 2x1 Dual Port Monitor Vga Switch 1920x1200 St122vga
| SKU: | 230501 |
|---|---|
| MPN: | ST122VGA Link |
| Manufacturer: | https://www.startech.com/ |
| Brand: | Startech |
| Warranty: | 1 Year Manufacturer's return to base |
| Availability: |
In stock |
| Fright Estimate |
Description
The ST122VGA 2-Port VGA Auto Switcher lets you share a display between two computers and automatically switch to the active source device using configurable priority switching. When the port you have selected as the primary input is turned off, the device automatically switches to the secondary input. For maximum control and versatility, the ST122VGA also offers manual switch control with an easy-to-use button that allows you to toggle between video sources.
For a convenient setup, the switcher can be powered using the included power adapter or the USB power cable, and features built-in EDID emulation ensuring maximum compatibility with your display or projector and support for resolutions up to 1920 x 1200 / 1080p.
- Share a laptop computer with a projector in boardrooms or trade shows, with automatic switching that ensures there's an active signal displayed on the screen even if the laptop is disconnected
- Connect and switch between multiple sources in test bench facilities, data centers, help desks, and video broadcasting facilities
- Connect two media players or PCs to your digital signage display, for more versatile messaging options
- Priority switching
- Automatic or manual port selection
- EDID emulation
- USB power cable
Specifications
| Connector(s) | |
| Connector A | VGA (15 pin, High Density D-Sub) Female |
| Connector B | VGA (15 pin, High Density D-Sub) Female |
| Environmental | |
| Humidity | 0% - 80 % |
| Operating Temperature | 0?C to 40?C (32?F to 104?F) |
| Storage Temperature | -10?C to 60?C (14?F to 140?F) |
| Hardware | |
| Audio | No |
| Industry Standards | EDID |
| Ports | 2 |
| Indicators | |
| LED Indicators | P1 (Port 1 selected) |
| P2 (Port 2 selected) | |
| Packaging Information | |
| Shipping (Package) Weight | 543 g [19.2 oz] |
| Performance | |
| Maximum Analog Resolutions | WUXGA (1920 x 1200)QWXGA (2048 x 1152) |
| Supported Resolutions | 1024 x 768, 1280 x 720, 1280 x 1024, 1366 x 768, 1440 x 900, 1600 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200, 1920 x 1440, 2048 x 1152 |
| Wide Screen Supported | Yes |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Aluminum |
| Product Height | 21 mm [0.8 in] |
| Product Length | 74 mm [2.9 in] |
| Product Weight | 175 g [6.2 oz] |
| Product Width | 59 mm [2.3 in] |
| Power | |
| Center Tip Polarity | Positive |
| Input Current | 0.4A |
| Input Voltage | 110V-240V AC |
| Output Current | 2A |
| Output Voltage | 5 DC |
| Power Consumption (In Watts) | 10 |
| Power Source | AC Adapter Included |
| What's in the Box | |
| Included in Package | 2-port VGA switch |
| instruction manual | |
| universal power adapter (NA, EU, UK, ANZ) | |
| USB power cable | |
Vendor Info
The ST122VGA 2-Port VGA Auto Switcher lets you share a display between two computers and automatically switch to the active source device using configurable priority switching. When the port you have selected as the primary input is turned off, the device automatically switches to the secondary input.
For maximum control and versatility, the ST122VGA also offers manual switch control with an easy-to-use button that allows you to toggle between video sources.
For a convenient setup the switcher can be powered using the included power adapter or the USB power cable, and features built-in EDID emulation ensuring maximum compatibility with your display or projector and support for resolutions up to 1920x1200/1080p.
The ST122VGA includes mounting hardware for a tidy and professional installation, and is backed by a 2-year StarTech.com warranty, and free lifetime technical support.
