Qnap Tvs-473e-8g 4-bay Nas Amd Rx-421bd 2.1~3.4 Ghz 8gb Ddr4 Ram (max 64gb) 4x 2.5"/ 3.5" + 2x M.2 2280/ 2260 Sata 6gb/ S Slots 4x Gbe Lan 2y Wty Tvs-473e-8g
$1,918.00
| SKU: | 271226 |
|---|---|
| MPN: | TVS-473e-8G Link |
| Manufacturer: | https://www.qnap.com |
| Brand: | Qnap |
| Warranty: | 1 Year Manufacturer's return to base |
| Availability: |
Preorder 2-3 weeks |
| Fright Estimate |
Description
▼
Specifications
▼
| CPU |
Processor: AMD R-Series RX-421BD quad-core 2.1 GHz processor, Turbo
Core up to 3.4 GHz Architecture: 64-bit Graphics: Embedded Radeon™ R7 graphics processor Encryption Engine: AES-NI |
| System Memory | 8 GB DDR4 (2 x 4 GB) |
| Maximum Memory | 64 GB (4 x 16 GB) |
| Memory Slot |
4 x SODIMM DDR4 (For dual- or quad-DIMM configurations, you must use a pair of identical DDR4 modules.) |
| Flash Memory | 512MB DOM |
| Drive Bay | 4 x SATA 6 Gbps |
| Drive Compatibility |
• 3.5-inch SATA hard disk drives • 2.5-inch SATA hard disk drives • 2.5-inch SATA solid state drives |
| M.2 SSD Slot |
2 x M.2 2260/2280 SATA 6Gb/s SSDs Note: 1. The M.2 SSD is not included as standard. 2. M.2 SSD operations can easily generate excessive heat. It is recommended to install a heatsink (from QNAP or a third-party provider) on the M.2 SSD. |
| SSD Cache Acceleration Support |
• Drive bays 1 to 4 • M.2 slots 1 to 2 • Optional: SSD using PCIe expansion slot |
| Hot-swappable |
Yes The following are not hot-swappable: M.2 SSDs, SSD cache drives, SSDs using PCIe expansion slots. |
| Gigabit Ethernet Port | 4 x RJ45 |
| USB QuickAccess Port | USB Micro-B |
| PCIe Slot |
2 x PCIe 3.0 x4 Note: Support 10GbE LAN card, USB 3.1 Gen2 (10Gb/s) expansion card, QM2 card, or PCIe wireless network card. |
| USB Port | 4 x USB 3.0 (Front: 1; Back: 3) |
| HDMI Output | 2 x HDMI 1.4b (up to 3840 x 2160 resolution at 30 Hz) |
| Audio |
• 2 x 3.5 mm dynamic microphone jacks • 1 x 3.5 mm line-out jack • 1 x speaker Note: You cannot use the speaker(s) and the line-out jack simultaneously. |
| Display Panel | Monochrome backlit LCD display with Enter and Select buttons |
| USB One Touch Copy | Front: USB 3.0 |
| IR sensor | QNAP RM-IR004 remote control (MCE compatible) (sold separately) |
| Form Factor | Tower |
| Dimensions (H x W x D) |
188.2 x 199.3 x 279.6 mm 7.41 x 7.85 x 11.01 inch |
| Net Weight | 4.9 kg (10.80 lbs) |
| Power Consumption (W) |
HDD standby: 33.24 W In operation: 56.23 W (with 4 x 2TB HDDs installed) |
| Sound Level | 21.7 dB(A) |
| Power Supply Unit | 250W, 100-240V AC, 50/60Hz, 3.5A |
| Fan |
System: 1 x 120 mm CPU: 1 x 60 mm |
| Operating Temperature & Relative Humidity | 0 ~ 40˚C ( 32˚F ~ 104˚F ), 5 ~ 95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Security Slot | Kensington security slot |
Note: Use only QNAP memory modules to maintain system performance and
stability. For NAS devices with more than one memory slot, use QNAP modules
with identical specifications. Warning: Using unsupported modules may
degrade performance, cause errors, or prevent the operating system from
starting.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
Vendor Info
▼
The TVS-473e is powered by a high-end AMD R-Series APU that incorporates an exceptional CPU with AMD Radeon™ R7 Graphics performance, delivering a high-performance and energy-efficient NAS solution. Built with a state-of-the-art metal design and topped off with a stylish gold finish, the highly-capable TVS-473e provides PCIe expandability, the unique USB QuickAccess port, HDMI 4K@ 30Hz output, and 4K H.264 video decoding and encoding acceleration for an optimum audiovisual experience.
